Tổng quan sản phẩm MÁY KIỂM TRA ĐỘ BÁM DÍNH VÀ KÉO GIÃN BĂNG KEO CHEMINSTRUMENTS MODEL DS-2000

Máy Kiểm Tra Độ Bám Dính Và Kéo Giãn Băng Keo (High Temperature 8 Bank Shear Tester) ChemInstruments Model DS-2000
DS-2000

Rugged construction, capable of withstanding the abuse of the production environment
Digital speed control with encoder feedback
Selectable speed range from 0.05 to 2 IPM in 0.005 IPM increments (0.15-5 CPM, 0.05 CPM increments)
Selectable test lengths from 0.25 to 1.5 inches in 0.25 inch increments (0.5 – 8.5 centimeters, 0.5 centimeter increments)
100 pound load cell is included with the machine
Capable of pulling up to 60 pounds (27 kg)
Accurate to +/-0.1% of load cell range
Operating temperature range: 32°-150° F (0°-70° C)
Capable of stand-alone operation with integrated 5.7 inch touch screen display
Data can be downloaded to EZ Data software for complete data management via USB connection
Universal input voltage from 85-265 VAC(50/60Hz)

Data Acquisition System

The ChemInstruments electronic data acquisition system is a state-of-the-art microprocessor controlled force measurement package that combines accuracy with ease of use. This system simultaneouslycontrols test motion, reads the force of a test from a load cell, stores that data in its memory and interfaces with EZ-Lab data management software to show the results graphically.
Displays the average, high and low measured force results immediately upon completion of a test
Export data by USB connection to a local PC with our EZ Data software
Displays test values in grams, kilograms, ounces, pounds or Newtons
Samples at 400Hz, 8 samples are collected, averaged and stored as a data point. A test will generate a data point every 20ms – For speeds of 0.35 – 2 IPM.
Samples at 50Hz, 8 samples are collected, averaged and stored as a data point. A test will generate a data point every 160ms – For speeds of 0.05 – 0.3 IPM

EZ Data
EZ Data Compatible Remote setup, operational control and enhanced data collection are all possible when coupled with our EZ-Lab data management software. This application requires an external PC.

Calibration Service
Calibration Service is available for this equipment.

Accessories
Essential:

Test panel – 2″ x 3″ (50mm x 75mm)
Hand roller – 4.5 lb (2 Kg)
Specimen tape cutter -1″ (25mm)

Non-Essential:

Various test panel sizes and materials
Custom sized hand rollers
Various sized specimen tape cutters
Test panel holder

Options

Additional load cell capacities available in 20 and 50 pounds
PSTC and TLMI testing manuals

Methods
Some of the more popular test methods that this device is capable of performing:

ASTM: D 1002, D 3163, D 3164
FINAT: FTM 18
